Description
SL-2000-P Offers
With the Dwyer SL-2000-P Photoelectric Duct Smoke Detector installed in your HVAC ducts, you can be notified to the presence of smoke or the products of combustion. The ionization detector functions in air velocities from 100 to 4,000 ft./min, and the unit will sound an alarm and use relays to disable fans and blowers for added safety.
Features
- Provides early detection of smoke and products of combustion within HVAC ductwork
- Measures within airflow with 100 to 4,000 ft./min velocity
- NEMA 1 enclosure rating
- Constructed with a plastic box back and a clear plastic cover for rugged strength
- Offers simple no-tool installation and servicing
- Integrated smoke test port
- Alarm contacts: 2 sets form “C” rated at 10 A resistive @ 115 VAC and 1 set form “A” rated at 2 A
- Trouble contacts: 1 set form “C” rated at 10 A @ 115 VAC
- Applications Commercial/Industrial/Residential HVAC, BAS Automation
